Inspektionssysteme

is one of the world’s leading suppliers of inspection systems for beverage bottling plants and has been active on the market for over 45 years.

In our devices, we use the latest measurement technology from image processing, optics and electronics. All for the benefit of the consumer!

Stay up to date

our product range

Empties

In front of the unpacker
Detection of foreign, horizontal and inverted bottles
Modern 3d measurement

miho Multicon 4

Embossing detection
Shape and color dinstinction
Sorting in up to 8 channels

Compact construction
Height and width measuring
Wide range of applications

miho TOP-Cam Detection of label and glue residue

Detects contamination at the finish, neck and body of the container
High-performance UV LED lighting system
Easy accessibility, maintenance-friendly design

In use over 500 times worldwide
Up to 72 000 bottles/hour
Hygienic design

miho TOP-Cam Finish inspection

Optical finish control (stand-alone)
State-of-the-art, digitalised and flexible colour camera mirror system
Easy accessibility, maintenance-friendly design

miho TOP-Cam Empty can inspection

Cans made of aluminium or tinplate, all shapes and sizes
Reliably detects defects or contamination on the rim, base and even on the inner side wall
Low space requirement

miho TOP-Cam Reusable cup inspection

Optical reusable cup control
Inspection of the base when the container is turned upside down
Bottom control with upside down containers

Compact construction
Test bottle function
Controls reject systems

Cap presence detection
After unpacker
Prevents disturbances in the further course

Closure presence detection
Hygienic design
Compact construction

Before the packer / crate washer
Controls left over
bottles and foreign objects
Modern 3d measurement

Full bottles

miho Newton HF2

Compact construction
High frequency technology
Easy to operate

miho Newton IR2

No ionizing radiation
Compact construction
Any filling product

miho Newton X2P

Pulsed X-ray technology
Low radiation
Any container type, any product

miho Newton X2Z

Line detector
Pulsed X-ray technology
Low radiation

miho Newton Optics 3

Precision fill level measurement
Very solid & low maintenance
Date/cap detection

miho Newton Optics Pro

Inspection of tethered caps
Inspection of the rotation of the cap
360° inspection

Filler monitoring
Localisation of faulty valve
Also as retrofit for filler modernization

Up to 12 sensors
In or behind the labeller
Swing top alignment detection

Modern color camera system
EAN barcode and expiry date imprint
Depending on the task, single- or multicamera setup

Optical 360° detection
Up to 60 000 containers/h
Inspects up to 5 labels

miho TOP-Cam Feature control UV

Control of container features, such as BBD, LOT no., on the shoulder of PET containers
Easy accessibility, maintenance-friendly design
Low space requirement

miho TOP-Cam Reflecting surface

Control of features such as BBD, LOT no., on closures
Inspection of the base when the container is turned upside down
No need to align the containers

miho TOP-Cam Matt surface

Control of non-reflective surfaces
Easy accessibility, maintenance-friendly design
Low space requirement

Vacuum detection viar lid scanning
Profile analysis by laser triangulation
Manual height adjustment

miho Top-Cam Feature surface

Control of container features, such as BBD, LOT no., on the shoulder of glass containers and tightness for swing-top bottles
Easy accessibility, maintenance-friendly design
Low space requirement : easy to integrate, also in
existing lines

Gentle bottle sensor wheel
Robust construction
Hygienic design

Pulsed X-ray technology
Minimal radiation exposure
Optional HSPM control

Controls packing completion
After the packer
Easy format changes

Controls packing completion
Many container shapes
Modern 3d measurement

Container transport

High level of precision
Smooth gap closure
Controlled by encoder

miho Conveyance

Low noise
Container friendly
Energy efficient

Rejection systems

Pneumatic pusher
Including compressed air reservoir
Including reject monitoring in the basic device

Linear drive
Up to 72 000 containers/h
Very wide range of containers

miho Leonardo SFM

Upright rejection on parallel track
Elektro-magnetic actuator, no compressed air
Compact design

miho Leonardo M

Magneto-mechanical
Tochless activation of sliders
Smooth and precise

For crates and cardboards

Electro-pneumatic
Safe and reliable
Cost-effective

No compressed air supply necessary
Gentle on containers
Robust, durable and low-maintenance

miho Leonardo SK-2W

Dynamic segmented rejecter miho SK-2W
2 way rejection

miho Leonardo SK-X

Dynamic segmented rejecter miho SK-X
3-way cross rejection

IT-Solutions

Production data logging
Comprehensive fault analysis
Weihenstephan Standard

miho Remote-Service

Exact fault analysis
Quick fault reset by an experienced engineer

Solutions for different types of bottles

in case of damage and contamination

Glass bottles

Swing-top bottles

PET returnable bottles
