Bottle sorting system miho Multicon 4

Shape and colour: Inspection device for sorting returnable bottles made of glass or plastic.
In addition to direct characteristics, the bottle can also be sorted on the basis of permanent labels (ACL), embossing or remaining adhesive residues.

Camera based system for the detection and sorting of glass or PET bottles or other containers according to shape, colour and size differences.

In addition, lying bottles or bottle breakages can be detected and rejected. The detection and evaluation of bottles may also be carried out via secondary features such as embossing, ACL or also via the degree of scuffing of the bottle. Sample bottles must be tested here.

The construction is made of stainless steel, is easily accessible and easy to maintain. A closed optical system and protective covers that can be opened without the use of tools, make it easy to clean the protective glass plates.

fries Zeichnungen aller Flaschen die inspeziert werden können
Fries zeichnungen aller Flaschen, die inspeziert werden können

Accessoires & modifications

miho hsp

High speed pusher
miho HSP

  • Pneumatic pusher
  • Up to 100 000 containers/h
  • Including reject monitoring
miho hspm

Multi-reject system
miho HSPM

  • Linear drive
  • Up to 72 000 containers/h
  • Very wide range of containers
miho leonardo m

Linear Reject System
miho Leonardo M

  • Magneto-mechanical
  • Gearless transmission drive
  • Smooth and precise
miho Leonardo SFM

Segment Reject System miho Leonardo SFM

  • Upright rejection on parallel track
  • Elektro-magnetic actuator, no compressed air
  • Compact design

Software package for the production data acquisition software miho AWeS. All production data, counters and test bottle protocol are logged according to the Weihenstephan standard. For all miho systems based on the miho VIDIOS® or miho MASTER® platform.

Software package for the remote visualization of the operating condition, the parameter and the camera images on an authorized computer. Monitoring of e.g. counters and malfunctions. Monitoring and remote control of the inspection machine by a miho service engineer, re-entry and optimization of the inspection parameters, exact and fast analysis of errors.
